PX0931/04/S Frequently Asked Questions (FAQs)

• What is the recommended torque for the connector's screw terminals?
  The recommended torque for the screw terminals is 0.5 Nm to 1.5 Nm, as specified by Bulgin's application notes.
• Can I use this connector in high-vibration applications?
  Yes, the PX0931/04/S is designed to withstand high-vibration environments, with a vibration resistance of 10-2000 Hz, 10G acceleration, as per IEC 60068-2-6.
• Is the connector suitable for outdoor use?
  Yes, the PX0931/04/S has an IP67 rating, making it suitable for outdoor use and providing protection against dust and water ingress.
• What is the maximum operating temperature range for this connector?
  The maximum operating temperature range for the PX0931/04/S is -40°C to 125°C, as specified in the datasheet.
• Can I use this connector with a wire size larger than 1.5 mm²?
  No, the PX0931/04/S is designed for wire sizes up to 1.5 mm². Using a larger wire size may compromise the connector's performance and reliability.
