M20-9721146 datasheet by Harwin

M20-9721146 Frequently Asked Questions (FAQs)

• What is the recommended torque for the M20-9721146 connector?
  The recommended torque for the M20-9721146 connector is 0.5 Nm to 1.5 Nm, as specified in the Harwin application notes.
• Is the M20-9721146 connector suitable for high-vibration applications?
  Yes, the M20-9721146 connector is designed to withstand high-vibration environments, with a tested vibration resistance of 10-2000 Hz, 10G peak acceleration.
• Can I use the M20-9721146 connector in harsh environments, such as high-temperature or humid conditions?
  The M20-9721146 connector is rated for operating temperatures from -40°C to +125°C and can withstand humid environments, but it's essential to follow Harwin's guidelines for environmental sealing and protection.
• What is the mating cycle life of the M20-9721146 connector?
  The M20-9721146 connector has a mating cycle life of 500 cycles minimum, as specified in the Harwin datasheet.
• Is the M20-9721146 connector compatible with automated assembly processes?
  Yes, the M20-9721146 connector is designed for automated assembly and can be used with pick-and-place machines, but it's essential to follow Harwin's guidelines for assembly and handling.
