D3088-97 datasheet by Harwin

D3088-97 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5 Nm to 1.5 Nm, depending on the wire size and type.
• Can I use the D3088-97 in high-vibration applications?
  Yes, the D3088-97 is designed to withstand high-vibration environments, but it's recommended to follow the manufacturer's guidelines for mounting and securing the connector.
• Is the D3088-97 compatible with wire sizes other than AWG 20-24?
  While the datasheet specifies AWG 20-24, the D3088-97 can accommodate smaller wire sizes (e.g., AWG 26-30) with the use of wire adapters or by following the manufacturer's guidelines for wire preparation.
• What is the maximum operating temperature for the D3088-97?
  The maximum operating temperature for the D3088-97 is 125°C, but it's recommended to derate the connector's current-carrying capacity at higher temperatures to ensure reliable operation.
• Can I use the D3088-97 in humid or wet environments?
  The D3088-97 has a IP67 rating, which means it can withstand temporary immersion in water, but it's not designed for continuous exposure to high humidity or wet environments. Additional sealing or protection may be required for such applications.
