The recommended PCB footprint for the D1213A-02SM-7 is a standard SOT23-6 package with a 1.5mm x 1.5mm body size. The datasheet provides a recommended land pattern and soldering guidelines.
To ensure proper soldering, follow the recommended soldering temperature profile and use a solder with a melting point between 220°C to 240°C. Apply a small amount of solder paste to the PCB pads and use a reflow oven or a hot air gun to solder the device.
The D1213A-02SM-7 has an operating temperature range of -40°C to 125°C. However, the device's performance and reliability may degrade if operated at the extreme ends of this range for extended periods.
Yes, the D1213A-02SM-7 is suitable for high-reliability and automotive applications. It meets the AEC-Q100 qualification standard for automotive-grade devices and is manufactured using a high-reliability process.
To prevent electrostatic discharge (ESD) damage, handle the D1213A-02SM-7 with an ESD wrist strap or mat, and ensure the workspace is ESD-protected. Avoid touching the device's pins or exposing it to static electricity.
D1213A-02SM-7 datasheet
by Diodes Incorporated
