The recommended PCB footprint for the B0520WS-7-F is a standard SOT23 package footprint with a minimum pad size of 1.5mm x 1.5mm and a thermal pad size of 2.5mm x 2.5mm.
To ensure proper soldering, use a soldering iron with a temperature of 250°C to 260°C, and apply a small amount of solder paste to the PCB pads. Use a soldering technique that minimizes the risk of overheating the component.
The maximum operating temperature range for the B0520WS-7-F is -40°C to 150°C, but it's recommended to operate within -20°C to 125°C for optimal performance and reliability.
Yes, the B0520WS-7-F is suitable for high-reliability and automotive applications, but it's essential to follow the recommended operating conditions, and ensure proper PCB design, layout, and manufacturing to meet the required reliability standards.
Store the B0520WS-7-F in its original packaging or an equivalent ESD-protective package, and avoid exposing it to extreme temperatures, humidity, or physical stress during shipping and storage.
B0520WS-7-F datasheet
by Diodes Incorporated
