Mini-Circuits provides a recommended PCB layout and footprint in their application notes. It's essential to follow these guidelines to ensure optimal performance and minimize parasitic effects.
Impedance matching is critical for optimal performance. Mini-Circuits provides guidance on impedance matching in their application notes. You can also use simulation tools like ADS or AWR to optimize the matching network.
The maximum power handling of the ADTL1-12+ is not explicitly stated in the datasheet. However, according to Mini-Circuits, the device can handle up to 1W of continuous power. Exceeding this limit may cause damage or affect reliability.
Yes, the ADTL1-12+ can be used in a push-pull configuration. However, it's essential to ensure that the devices are properly matched and biased to avoid uneven current sharing and potential reliability issues.
The thermal resistance of the ADTL1-12+ is not explicitly stated in the datasheet. However, according to Mini-Circuits, the thermal resistance is approximately 25°C/W. Proper thermal management is crucial to ensure reliable operation.
ADTL1-12+ datasheet
by Mini-Circuits
