ACPL-827-500E Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance of the ACPL-827-500E?
  Broadcom recommends a PCB layout with a solid ground plane, minimal track length, and a 50-ohm transmission line for the output stage to ensure optimal performance and minimize electromagnetic interference (EMI).
• How do I ensure reliable operation of the ACPL-827-500E in high-temperature environments?
  To ensure reliable operation in high-temperature environments, it is recommended to follow proper thermal management practices, such as providing adequate heat sinking, using a thermally conductive PCB material, and keeping the device within its specified operating temperature range.
• What is the maximum allowable voltage on the VCC pin of the ACPL-827-500E?
  The maximum allowable voltage on the VCC pin of the ACPL-827-500E is 5.5V. Exceeding this voltage may damage the device or affect its reliability.
• Can I use the ACPL-827-500E in a galvanically isolated system?
  Yes, the ACPL-827-500E is designed for galvanic isolation and can be used in systems that require electrical isolation between the input and output stages.
• What is the typical propagation delay of the ACPL-827-500E?
  The typical propagation delay of the ACPL-827-500E is around 100 ns, but this can vary depending on the specific application and operating conditions.
