Wurth Elektronik provides a recommended PCB layout and land pattern in their application notes and layout recommendations, which can be found on their website or through their customer support. It's essential to follow these guidelines to ensure proper assembly and performance of the component.
Wurth Elektronik recommends following standard SMD assembly and rework procedures, including using a soldering iron with a temperature of 260°C (max) and a soldering time of 3 seconds (max). Additionally, using a hot air soldering station with a temperature of 220°C (max) and an air flow of 1 liter/minute (max) is also acceptable. It's essential to avoid overheating, excessive mechanical stress, and exposure to moisture.
The 744314760 is rated for operation from -40°C to +125°C, but it's essential to note that the component's performance and reliability may degrade at extreme temperatures. It's recommended to consult the datasheet and application notes for specific temperature-related information and to ensure the component is used within its specified operating range.
Wurth Elektronik provides information on the 744314760's EMC performance in their datasheet and application notes. Additionally, it's recommended to consult with Wurth Elektronik's technical support or an EMC expert to ensure the component meets the specific EMC requirements of your application.
Wurth Elektronik recommends storing the 744314760 in its original packaging, away from direct sunlight, moisture, and extreme temperatures. It's also essential to handle the component by the edges, avoid touching the pins, and use anti-static precautions to prevent ESD damage.
