20FMN-BMTTN-A-TF datasheet by JST Manufacturing

20FMN-BMTTN-A-TF Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5 N·m to 1.5 N·m (0.37 lbf·in to 1.06 lbf·in).
• Can I use this connector in high-vibration applications?
  Yes, the 20FMN-BMTTN-A-TF is designed to withstand vibrations up to 10 Hz to 2000 Hz, with an amplitude of 1.5 mm (0.06 in) in the X, Y, and Z directions.
• Is this connector suitable for outdoor use?
  Yes, the 20FMN-BMTTN-A-TF has a rating of IP67, which means it is protected against dust and can withstand immersion in water up to 1 meter (3.3 feet) for 30 minutes.
• What is the operating temperature range for this connector?
  The operating temperature range for the 20FMN-BMTTN-A-TF is -40°C to 105°C (-40°F to 221°F).
• Can I use this connector with wire sizes other than 20 AWG?
  While the connector is designed for 20 AWG wire, it can accommodate wire sizes from 18 AWG to 22 AWG, but the wire stripping length and insulation diameter may need to be adjusted accordingly.
